| type | d (mm) | d1 (mm) | d2 (mm) | d3 (mm) | d4 (mm) | dk (mm) | G | B (mm) | C1 (mm) | l3 (mm) | l4 (mm) | l7 (mm) | W (mm) | h1 (mm) | tilt angle alpha (°) | weight (kg) | basic load rating dyn C (kN) | basic load rating stat Co (kN) | radial clearance CN (?m) | d (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DGIR / DGIL 45 UK-2RS | 45 | 50 | 102 | 58 | 70 | 60 | M 42 x 3 | 32 | 27 | 65 | 196 | 52 | 60 | 145 | 7 | 2.5 | 92.7 | 192 | 0 - 60 | 45 |
- 产品型号: DGIR/DGIL45UK-2RS
- 主要类别：杆端关节轴承
- 应用行业:tube,scientific instruments,marine analysis and testing equipment,packaging materials,organic raw materials,historical instruments,Surveying Surveying Instruments,Gas turbine,survey accessories,Leather Products,other processing
- 近似型号:DGIR / DGIL 6 UK DGIR / DGIL 17 UK (-2RS) DGIR / DGIL 20 UK (-2RS) DGIR / DGIL 15 UK DGIR / DGIL 30 UK (-2RS) DGIR / DGIL 25 UK (-2RS) DGIR / DGIL 12 UK DGIR / DGIL 10 UK DGIR / DGIL 50 UK-2RS DGIR / DGIL 8 UK
DGIR/DGIL45UK-2RS DGIR/DGIL80UK-2RS DGIR/DGIL35UK-2RS DGIR/DGIL10UK DGIR/DGIL60UK-2RS DGIR/DGIL12UK DGIR/DGIL20UK(-2RS) DGIR/DGIL40UK-2RS DGIR/DGIL70UK-2RS DGIR/DGIL8UK DGIR/DGIL40UK-2RS DGIR/DGIL50UK-2RS - 天津八零动力国际贸易有限公司专业经销德国DURBALDGIR/DGIL45UK-2RS轴承，常年备货杜巴丽DURBAL DGIR/DGIL45UK-2RS 杆端关节轴承. 我们可以快速将您所需要的德国杜尔巴DURBALDGIR/DGIL45UK-2RS产品运送到全球任意地方购买 DURBAL DGIR/DGIL45UK-2RS 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 杆端关节轴承订购电话022-58519723/22/21
