| type | right hand thread | left hand thread | d (mm) | G | B (mm) | C1 (mm) | h (mm) | d1 (mm) | d2 (mm) | d3 (mm) | l1 (mm) | l2 (mm) | l7 (mm) | e (mm) | tilt angle alpha (°) | weight (kg) | rotational speed limit n max. (min-1) | axial factor Y | axial factor Y0 | basic load rating dyn C (kN) | basic load rating stat Co (kN) | radial clearance CN (?m) | d (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PM 06 - 01 | -501 | -502 | 6 | M 10 x 1 | 14 | 10 | 40.5 | 8.5 | 24 | 14 | 19 | 52.5 | 17 | 1.5 | 10.5 | 0.057 | 1300 | 1.28 | 1.34 | 2.5 | 0.8 | 10 - 30 | 6 |
- 产品型号: PM06-01
- 主要类别：杆端关节轴承
- 应用行业:wall industry,Hydraulic Rama,Broadcasting System,security equipment,Cylinder Type,Technical Equipment,other mold,medical equipment,noise reduction equipment,quality inspection equipment,Spectrum Products
- 近似型号:PM 06 - 00 PM 06 - 01 PM 17 - 00 PM 08 - 01 PM 10 - 01 PM 08 - 00 PM 15 - 00 PM 17 - 01 PM 12 - 01 PM 20 - 00
PM10-00 PM06-01 PM12-00 PM10-01 PM20-00 PM06-00 PM08-00 PM08-01 PM17-00 PM20-01 PM06-00 PM08-00 - 天津八零动力国际贸易有限公司专业经销德国DURBALPM06-01轴承，常年备货杜巴丽DURBAL PM06-01 杆端关节轴承. 我们可以快速将您所需要的德国杜尔巴DURBALPM06-01产品运送到全球任意地方购买 DURBAL PM06-01 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 杆端关节轴承订购电话022-58519723/22/21
